Wheels Mfg 386EVO Threaded A/C BB SRAM
Description
Threaded BB for 386EVO frames and 22/24mm diameter spindle cranks. Machined cups thread together for stability, increased bearing life, and simple installation and maintenance.In Angular Contact (A/C) bearings, ALL balls are engaged and spread the force over a larger surface area, to decrease friction and minimize wear.
No more creaking. Smooth operation. Fast bearing replacement.
Notes:
Wheels Mfg 386EVO BB for use with 24/22mm spindle cranks will not work with Quarq SRAM/GXP cranksets (Elsa, Riken, SRAM Red 22, SRAM S975, SRAM S2275, CinQo Saturn, Saturn2). If your Quarq spider has an ID less than 49.5mm, your crank may rub on the BB cup.
Compatible with Quarq DZero powermeter spiders with GXP spindles except Eagle MTB.
Bottom Bracket/Frame Interface: BB386EVO, BB392EVO
Bottom Bracket Shell Width (mm): 86mm - 92mm
Bottom Bracket Shell I.D.: 46mm
Webshops and Bike shops
You may also be interested in...
-
Stock Code:WMBB-PF30-THD-BB
New PF30 bottom bracket with threaded cups. Don't rely on questionable frame tolerances. Our threaded cups ensure a tight, noise-free bottom bracket with proper bearing alignment.
Direct replacement for SRAM, FSA, and other PressFit 30 bottom brackets!
- Bearings: Enduro ABEC-3
- Bottom Bracket/Frame Interface: PF30, BBRight™ Press Fit, Specialized Carbon OSBB*
- Bottom Bracket Shell Width (mm): 61mm to 79mm*
- Bottom Bracket Shell I.D.: 46mm
- Crank Spindle Diameter: 30mm
- Will accept 24mm and 24/22mm cranksets using Wheels Mfg. adapter shims
* Specialized Carbon OSBB with 61mm shell width will need additional 3.5mm cup spacers.
** Note: Use only bottom bracket tools compatible with 16-notch MegoEvo BB’s. (FSA MegaEvo and Park Tool BBT-29).$241.50 (RRP)Add To Cart
-
Stock Code:WMBB-T47-BB-SRAM-AC
T47 threaded BB cups for T47 frames and 22/24mm diameter spindle cranks. Cups have internal bearings, and are typically used in BB shells with widths wider than 73mm. Machined aluminum cups thread together directly into a T47 BB shell. Bearings are easily serviced or replaced. Includes sleeve to fit between cups for added protection from dirt and grime, and also keeps your internal wires and hoses from rubbing on the crank spindle. In Angular Contact (A/C) bearings, ALL balls are engaged and spread the force over a larger surface area, to decrease friction and minimize wear.
T47 BB cups are similar to standard BSA threaded cups in that the drive side cup is left-hand thread and the non-drive side cup is right-hand thread. Use a quality grease when installing in steel or aluminum BB shells, and an anti-seize compound compatible with titanium BB shells.
** Notes:
Wheels Mfg T47 internal bearing BB for use with 24/22mm spindle cranks may not work with Quarq SRAM/GXP cranksets (Elsa, Riken, SRAM Red 22, SRAM S975, SRAM S2275, CinQo Saturn, Saturn2) when used in BB shells with widths of 86.5mm and wider. If your Quarq spider has an ID less than 49.5mm, your crank may rub on the BB cup.
Compatible with Quarq DZero powermeter spiders with GXP spindles except Eagle MTB.$241.50 (RRP)Add To Cart
-
Stock Code:WMBB-T47-OUT-SHIM-BB
T47 threaded BB cups for T47 frames and 24.00mm spindle diameter cranks. Cups have outboard bearings, and are typically used in BB shells with widths from 68mm to 100mm. Machined aluminum cups thread together directly into a T47 BB shell. Bearings are easily serviced or replaced. Includes sleeve to fit between cups for added protection from dirt and grime, and also keeps your internal wires and hoses from rubbing on the crank spindle.
T47 BB cups are similar to standard BSA threaded cups in that the drive side cup is left-hand thread and the non-drive side cup is right-hand thread. Use a quality grease when installing in steel or aluminum BB shells, and an anti-seize compound compatible with titanium BB shells.
Bottom Bracket Includes:
BB Cups with bearings
2 - Silicone dust seals
2 - 0.5mm crank spindle spacers
2 - 1.0mm crank spindle spacers
Bearings: Enduro ABEC-3
Bottom Bracket/Frame Interface: T47
Bottom Bracket Shell Width (mm): 68mm - 100mm
Bottom Bracket Shell I.D.: 47x1.0mm Threaded
Crank Spindle Diameter: 24.00mm
Over Bearing Width: 90.8mm in 68mm wide shell*
Tool Pattern: 44mm x 16-notch
Weight: 150g$273.00 (RRP)Add To Cart
-
Stock Code:BTBB-4055822522090
Seido T47 BBs are machined to precision with the highest quality aluminium and bearings. They will fit 30mm spindle cranks with the included washers, or can be fitted with our adaptor kits to accept other sizes as well.
The internal provides room for internal cable routing. Servicing or replacing bearings is an easy job thanks to a great accessibilty of the bearing races, even when still fitted inside the frame. Outer seals provide extra protection for the already double-sealed bearings.
Uses 2x 6808 bearings (30x40x7mm, ID x OD x t).
SUITABLE BB SHELL WIDTH
68mm - 73mm
Includes 2 x 1.5 mm, 4 x 1 mm, 1x wave washer Removable Nylon Sleeve Adaptable to 24 and 24 / 22 mm with our spindle adapters$120.00 (RRP)Add To Cart
-
Stock Code:WMBB-SRAM-SPACER-PK
Replacement spacer pack for Wheels Mfg 22/24mm (GXP) bottom brackets.
Pack Includes:
1 - Silicone Dust Seal, 24mm ID Drive Side
1 - Silicone Dust Seal, 22mm ID Non-drive Side
1 - 24MM Wave Washer
2 - 0.5mm, 24mm ID Crank Spindle Spacer
2 - 1.0mm, 24mm ID Crank Spindle Spacer$45.00 (RRP)Add To Cart
