SOMA OXFORD HANDLEBAR
Soma Oxford bar 25.4x540x52mm Polished Silver Alloy (Back Sweep 155mm)
Webshops and Bike shops
Related Products
-
Description
Road bar with a round compact bend and shallow drop. Shape makes it easy to get into a natural position in the drops and brake levers are within easy reach.
- 6061-T6 aluminum
- Drop: 130mm
- Reach: 75mm
- 26.0 or 31.8mm center
- Single groove -
Description
Our road bar features a mild wing shape on top, clamping area wide enough for aero bars, mid-compact reach and drop. This is the modern bar for the modern road bike. Our Road bar wing section is small enough not to restrict hand movement when riding on the top and allows bar angle adjustment with out “locking out” your wrists. Shaping on the bottom side of the wing allows housing to be taped out of the way without the use of narrow housing channels or internal routing, both of which shorten bar life. Certified to EN, tested to DIN+.
Layup uses 3 different fiber types with different tensile strengths and tensile modulus, including High Strength carbon fiber. This helps allocate stiffness and flex where needed.
All carbon fiber is produced by Toray and uses tailor made Nano Epoxy Resin for very high impact resistance. Toray is the main supplier of carbon fiber for Boeing and Airbus.
Both the Road and Cross bar are made in one piece, not three pieces co-molded and glued together.
Bars are molded over an EPS mandrel to avoid wrinkles inside the layup during molding. Most other bars are molded over inflatable nylon bladders.
1.5K woven impact ends help prevent damage to uni-directional fibers from impact.
Reach 78.5mm.
Drop is proportional. Road drops are: 40CM 137mm, 42CM 140mm, 44CM 140mm, 46CM 143mm -
Description
A roomy riser bar with about 25° of backsweep for a natural wrist position. Offers comfort without sacrificing hardly any control. Dream Cycle Vancouver helped us design this model. They wanted to replicate something close to bars found on MTB bikes of the early 80's. Recommended for bikepacking and touring.
– 6061 T6 aluminum
– 780mm width
– 50mm rise
– 31.8mm center
– 25° backsweep
– 5° upsweep
– 420 gramsExpected Date:06 June 2024 -
Description
Designed to combine what’s good about drop bars with the benefits of a riser, the Truck Stop Bar offers welcome relief to the road-weary traveler. Just like with a standard drop bar, you’ll have multiple hand positions at your disposal so you can stay comfortable and in control for the long haul down the Big Slab. And if it’s a more relaxed, upright riding position you’re after, 30mm of rise will get you there. So, if you’ve accidentally or intentionally cut your steer tube too short, here’s your chance at redemption. Also suitable for taller riders who’ve exhausted all other options for rise, it comes in three widths of 42, 45, and 48cm. Lightweight aluminum construction, CB radio not included.
Specifications:
Material: Aluminum
Clamp Diameter: 31.8mm
Width: 42cm, 45cm, or 48cm
Rise: 30mm
Sweep Angle: 12 degreesPOA -
Description
Cowchipper provides comfort, control, and efficiency for long days in the saddle, whether road touring, crushing mixed surfaces, or conquering the Great Divide. While the Cowchipper retains some resemblance of a traditional road bar, its radical 24 degree flare in the drops boosts leverage, stability, and comfort dramatically.
- Lightweight and strong 7050-T76 series alloy construction with polished finish
- Drop/Reach: 116/68mm
- 31.8mm clamp diameter with 120mm width for use with Salsa Anything Cradle and aerobars
- 24 deg flare and 12 deg drop anglesPOA
