Forks
-
Stock Code:SMFK23280
This fork is only to be sold with Wolverine frames or as a replacement for a Wolverine. We don't stock enough for general sales. - Flat lugged crown
– Tange Infinity CrMo steel
– Flat lugged crown
– IS Disc mount
– Double eyelets at fork tips
– Mini rack mounts
– Low rider pannier mounts
– 50mm rake
– 400mm axle to crown$350.00 (RRP)Add To Cart
-
Stock Code:SMFK23281
For those who want a little more front end stiffness out of their Wolverine.
– Tange Infinity CrMo
– Unicrown straight blade
– 405mm axle to crown
– 50mm rake
– Fits 700x45mm tires with
fenders (this has slightly less
clearance than the lugged)
– Low rider pannier mounts
* 15mm TRU-AXLE INCLUDED$350.00 (RRP)Add To Cart
-
Stock Code:SMFK231909
A tough unicrown fork option for the Soma Wolverine and other gravel/CX frames with a 1-1/8" headtube. Version 3 model has a new fork end design and adopts the flat mount disc standard.
– Tange Infinity CrMo
– Unicrown straight blade
– 405mm axle to crown
– 50mm rake
– Fit flat mount disc (160mm rotor - with adapter)
– Fits 700x45mm tires with fenders (this has slightly less clearance than the lugged crown fork)
– Triple bosses on fork leg to fit low rider pannier rack or cage
– 15 x 100mm thru-axle included
– Weight: 3.3 lbs (with uncut 350mm steerer and thru-axle bolts)$390.00 (RRP)Add To Cart
-
Stock Code:SMFK230060
Matching fork for the Soma Jawbone A-Type frame.
- Tange CrMo steel
- Steve Potts Type II-R construction
- Axle to Crown: 420mm
- Rake: 50mm
- Investment cast thru-axle dropouts (12mm x 100mm)
- One set of cargo cage bosses per leg, lowest boss can be used for a pannier rack
- IS disc mount
- Sage Green w/ black
If you are getting this fork for the Jawbone, you need a ZS44 headset.
* Since this is for matching to a frame, we reserve the right to restrict sales of this item to customers who are buying a frame.Expected Date:06 June 2024POA -
Stock Code:SMFK230062
Matching fork for the Soma Jawbone B-Type frame.
- Tange CrMo steel
- Fits QR hubs
- Axle to Crown: 420mm
- Rake: 50mm
- IS disc mounts, rotor fit up to 180mm
- Two sets of cargo cage bosses per leg, pannier rack bosses on inside and outside leg
- Two sets of fender/rack eyelets at fork ends
If you are getting this fork for the Jawbone, you need a ZS44 headset.
*Since this is for a frame and we have limited quantities, we reserve the right to restrict sales to only customers purchasing the Jawbone frame.Expected Date:06 June 2024POA -
Stock Code:SMFK231913
A rigid fork for early 90's mountain bikes with 1" threaded steerer forks. The length is good match for a frame that was designed for a Rock Shox Judy 63mm travel fork.
Measure your current suspension fork at its recommended sag to determine if this rigid fork is a good replacement for your bicycle.
– Tange Chromoly steel
– Axle to crown: 425mm
– Cantilever bosses (no disc mounts)
– Rake: 40mm
– 50mm of threads
(26" wheels only of course)POA -
Stock Code:SLFK-FK0949
The Bridge Club fork is designed around the 27.5 wheel size with tire clearance up to 2.8", but is also capable of running 700c wheel setups with max tire clearance of 47c. It has 51mm I.S. disc caliper mounts and brake line guides as well. It only has the barnacles that matter most to the discerning bike tourist.
- Upper and lower barrel bosses
- One set of three pack mount on each leg
- Mid-blade eyelets
- Lower rack and fender mounts on the fork ends
- Max tire clearance up to 2.8”
Axle to Crown Length: 420 mm
Brake Mount (Fork): IS Disc Brake 160
Front Axle: QR x 100mm
Material: Steel
Offset: 43 mmPOA -
Stock Code:SLFK-FK0117
Our lugged and brazed Cross-Check/Travelers Check fork has room for 700c x 45mm tires and fenders. It’s made from 4130 CroMoly steel and features fender eyelets at the dropouts, cantilever brake pivots, and now has through-leg mid-blade eyelets for mounting a rack. The eyelets are threaded 5 x 1mm and located 165mm up from the axle.
- 1-1/8" threadless steertube
- Finish is black powdercoat.
- Axle-To-Crown: 400mm
- Rake: 44mm
- Steerer: 300mm
- Weight: 1-1/8" = 1 .00 kg uncut.POA -
Stock Code:SLFK-FK0362
Surly Dinner 27.5" Rigid Fork - 50mm Offset - 1 1/8" Ahead - 15x110mm - Black
The Dinner Fork is non-suspension corrected and accommodates 26”, 27.5”, and 29” wheel sizes. If you want to run fenders alongside an 8 or 24-Pack style rack, this fork can do that. Hell, it relishes it. To give you even more options for carrying miscellaneous items, we put a set of 3-pack mounts on each fork blade, too.
Run it on your current Surly for a thought-provoking new experience, or throw it on a different rig to unlock some off-road capabilities. A truly versatile piece of cutlery, the Dinner Fork features 100% Surly Chromoly steel construction, 51mm IS disc brake mounts, and clearance for tires up to 26 x 3.0”, 27.5 x 2.8”, or 29 x 2.2”.
Specifications:
Axle-to-crown: 420mm
Offset: 50mm
Steerer: 350mm, 1-1/8” straight
Tyre Clearance: 26 x 3.0” (without fenders); 27.5 x 2.8” (with or without fenders); or 29 x 2.2” (without fenders)POA -
Stock Code:SLFK-FK1477
Equipped to make touring the wide world’s paved roads a little more comfortable, the Disc Trucker Thru-Axle Fork has three-pack mounts on each blade to give you space for racks, fenders, and additional cargo solutions. Available in 26? and 700c wheel sizes, it offers dynamo routing, a 1-1/8? threadless steerer tube, and compatibility with 12mm captured thru-axles and flat-mount disc brakes.
Brake Mount (Fork): Flat Mount 160
Wheel Size: 26"
Crown Race: 30
Front Axle: 12mm Thru x 100mm
Steerer Type: Straight
Offset: 45
Material: Steel
Steerer Tube Length (mm): 400
Maximum Tire Clearance (Fork): 26x2.1
S.H.I.S. Stem Clamp Diameter: 28.6
Axle to Crown Length: 376
Max Rotor Size (Fork): 160POA -
Stock Code:SLFK-FK0916
The Disc Trucker Fork. The classic Long Haul Trucker fork is now available in a disc brake option. Fear not the loaded descent.
· 100% CroMoly steel construction, curved blades, powdercoated
· Extensive mounting options with threaded eyelets in four locations: double eyelet dropouts, mid-blade, and a pair drilled into the fork crown
· 51mm IS disc brake mount
· 26" has clearance for a 2.1" tire
Specifications
Axle to Crown Length: 376 mm
Brake Mount (Fork): IS Disc Brake 160
Color: Black
Crown Race: 30
Defined Color: Black
Front Axle: 10mm x 100mm
Material: Steel
Maximum Tire Clearance (Fork): 45 mm
Offset: 45 mm
Rotor Size (Fork): 160
S.H.I.S. Stem Clamp Diameter: 28.6
Steerer Tube Length (mm): 400 mm
Steerer Type: Straight
Weight: 955 g
Wheel Size: 26"POA -
Stock Code:SLFK-FK1479
Equipped to make touring the wide world’s paved roads a little more comfortable, the Disc Trucker Thru-Axle Fork has three-pack mounts on each blade to give you space for racks, fenders, and additional cargo solutions. ,it offers dynamo routing, a 1-1/8? threadless steerer tube, and compatibility with 12mm captured thru-axles and flat-mount disc brakes.
Brake Mount (Fork): Flat Mount 160
Wheel Size: 700c
Crown Race: 30
Front Axle: 12mm Thru x 100mm
Steerer Type: Straight
Offset: 45
Material: Steel
Steerer Tube Length (mm): 350
Maximum Tire Clearance (Fork): 700x50
Axle to Crown Length: 390
Max Rotor Size (Fork): 160POA -
Stock Code:SLFK-FK1478
The Disc Trucker Fork. The classic Long Haul Trucker fork is now available in a disc brake option. Fear not the loaded descent.
- 100% CroMoly steel construction, curved blades, powdercoated
- Extensive mounting options with threaded eyelets in four locations: double eyelet dropouts, mid-blade, and a pair drilled into the fork crown.
Brake Mount (Fork): Flat Mount 160
Steerer Type: Straight
Offset: 45 mm
Material: Stainless Steel
Steerer Tube Length (mm): 350 mm
Maximum Tire Clearance (Fork): 700x50
Front Axle: 12mm Thru x 100mm
Axle to Crown Length: 390 mm
Max Rotor Size (Fork): 160POA -
Stock Code:SLFK-FK0917
Surly Long Haul Trucker Fork 700c w/ Logo Crown Black
The Long Haul Trucker fork is designed to mount racks and fenders and to haul stuff. 700c wheel sizes, the fork’s new crown provides ample clearance for 700c x 50mm tires, and sports threaded eyelets in four locations (dual dropout, midblade and fork crown) to provide more options for mounting stuff, from racks to whatever. Options galore. Curved blades, CroMoly steel. 1-1/8? threadless steer tube, black powdercoat finish.
Options:700c
Axle-to-crown:390mm
Offset: 45mm
Steerer: 700c (56–64cm frames) = 350mm
Tire Clearance:700c x 45mm
Weight:700c = 2.3 lb uncutPOA -
Stock Code:SLFK-FK0659
The ECR fork features accommodations for a rack and fenders, a set of Three-Pack cage mounts on each leg, disc brake mounts and brake line guides. Constructed using the same 4130 CroMoly steel as Surly’s frames and forks, with an 1-1/8” steerer.
Butted and tapered blades
Barrel bosses at the dropouts and crown
Mid-blade thru-blade eyelets
Three-Pack cage bosses on each fork leg
QR Dropouts
Fits tires up to 27.5 x 3” wide
Axle to Crown Length: 447 mm
Brake Mount (Fork): IS Disc Brake 160
Front Axle: QR x 100mm
Material: Steel
Offset: 43 mm
S.H.I.S. Stem Clamp Diameter: 28.6
Steerer Type: Straight
Steerer Tube Length (mm): 285 mm
Weight: 1240 gPOA -
Stock Code:SLFK-FK0040
Surly Ice Cream Truck 150x15 Thru Axle Fork Black
Brake Type: Disc
Brake Usage F/R: Front
Color: Black
Crown Race: 30.0
Defined Color: Black
Front Axle Type: 15mm Thru
Front Hub Spacing (mm): 150 mm
S.H.I.S. Stem Clamp Diameter: 28.6
Wheel Size: 26"POA -
Stock Code:SLFK-FK0026
Surly Krampus 29" Fork 1-1/8" Threadless Black Boss Model with Mounts
Brake Type: Disc
Brake Usage F/R: Front
Color: Black
Crown Race: 30.0
Defined Color: Black
Front Axle Type: 9x1
Front Hub Spacing (mm): 100 mm
S.H.I.S. Stem Clamp Diameter: 28.6
Steerer Type: Straight
Wheel Mount Center Offset (mm): 0 mm
Wheel Size: 29er
Axle to Crown Length: 483 mmExpected Date:06 June 2024POA -
Stock Code:SLFK-FK0911
The Long Haul Trucker fork is designed to mount racks and fenders and to haul stuff.The fork’s new crown provides ample clearance for 26 x 2.1, and sports threaded eyelets in four locations (dual dropout, midblade and fork crown) to provide more options for mounting stuff, from racks to whatever. Options galore. Curved blades, CroMoly steel. 1-1/8 threadless steer tube, black powdercoat finish.
Options: 26
Axle-to-crown: 26? = 376mm
Offset: 45mm
Steerer: 26 (42–54cm frames) = 300mm
26(56–62cm frames) = 400mm
Tire Clearance: 26 x 2.1
Weight: 26 = 2.1 lb (0.97kg) uncutExpected Date:06 June 2024POA -
Stock Code:SLFK-FK0912
Surly Long Haul Trucker Fork 700c w/ Logo Crown Black
The Long Haul Trucker fork is designed to mount racks and fenders and to haul stuff. 700c wheel sizes, the fork’s new crown provides ample clearance for 700c x 50mm tires, and sports threaded eyelets in four locations (dual dropout, midblade and fork crown) to provide more options for mounting stuff, from racks to whatever. Options galore. Curved blades, CroMoly steel. 1-1/8? threadless steer tube, black powdercoat finish.
Options:700c
Axle-to-crown:390mm
Offset: 45mm
Steerer: 700c (56–64cm frames) = 350mm
Tire Clearance:700c x 45mm
Weight:700c = 2.3 lb uncutPOA -
Stock Code:SLFK-FK0653
Designed with the Midnight Special frame, this fork is built for comfort and speed on long road rides. It features a weight-saving uni-crown design, flat mount disc brakes, and a 12mm x 100mm thru-axle dropout as well as braze-ons for fenders and racks.
100% CroMoly construction, fully brazed crown
Mid-blade thru-blade eyelets
Rack and fender eyelets at the dropout
12mm x 100mm thru-axle
Clearance for 27.5” x 2.32” or 700c x 42mm tires
50MM OFFSETPOA -
Stock Code:SLFK-FK0652
Designed with the Midnight Special frame, this fork is built for comfort and speed on long road rides. It features a weight-saving uni-crown design, flat mount disc brakes, and a 12mm x 100mm thru-axle dropout as well as braze-ons for fenders and racks.
100% CroMoly construction, fully brazed crown
Mid-blade thru-blade eyelets
Rack and fender eyelets at the dropout
12mm x 100mm thru-axle
Clearance for 27.5” x 2.32” or 700c x 42mm tires
40mm offset
Axle-to-crown 400mmPOA -
Stock Code:SLFK-FK0658
The Ogre fork is ready for just about anything. Made with 100% Chromoly and compatible with both 29” and 27.5+ wheel sizes, generous tire clearance, and available in suspension and non-suspension corrected options.
- 100% Chromoly
- Straight steerer tube
- Mid though-blade threaded rack eyelets
- High and Low-blade threaded barrel boss rack eyelets
- 51mm IS disc brake tabs
- Removable canti brake pivots, compatible with 29” rims only
- Axle to Crown Length: 447 mm
- Offset: 43 mm
- Steerer Tube Length (mm): 285 mm
- Rotor Size (Fork): 180
- Maximum Tire Clearance (Fork): 3"POA -
Stock Code:SLFK-FK3002
Surly Steamroller Fork 700c 1-1/8" Threadless Black
· CroMoly tubing, flat crown, brazed construction
· Accepts tires up to 700c x 38mm, drilled for standard-reach brake
· No eyelets
· 9mm Brake Bolt to Crown Length
- Axle to Crown Length (mm): 375 mm
- Fork Rake (mm): 38 mm
- Steerer Tube Length (mm): 300 mmPOA -
Stock Code:SLFK-FK0952
Specifications
Axle to Crown Length: 380 mm
Brake Mount (Fork): IS Disc Brake 160
Color: Black
Crown Race: 30
Defined Color: Black
Front Axle: 10mm x 100mm
Material: Steel
Maximum Tyre Clearance (Fork): 650b x 48mm
Offset: 44 mm
Rotor Size (Fork): 160
S.H.I.S. Stem Clamp Diameter: 28.6
Steerer Tube Length (mm): 360 mm
Steerer Type: Straight
Weight: 1134 g
Wheel Size: 650bPOA
