Tange LN3922 73x115mm JIS
Description
Tange-Seiki LN 3922 JIS cartridge bottom bracket features ultra-smooth sealed cartridge bearings, solid boron steel spindle and steel cups.
- 73mm English-threaded (1.370" x 24 tpi)
- JIS square taper
- steel cups & sleeve
- requires Park Tool BBT-22 for installation & removal
- crank arm bolts are not included
Webshops and Bike shops
You may also be interested in...
-
Stock Code:WMBB-PF30A-OUT-SHIM
The two machined aluminum cups thread together ensuring the bottom bracket remains stable in the frame, increasing bearing life, and simplifying maintenance. This means no more creaking, smoother operation, longer bearing life, and really quick bearing replacement.
Specifically designed for installing 24.00mm spindle diameter cranks (Shimano, Etc.) in Cannondale PF30A (46mm ID, 73mm wide asymmetrical BB shell) frames without the need for any adapters.
**Note: FSA MegaExo spindles can be between 24.00mm and 24.07mm in diameter. If your FSA spindle is 24.07mm, this BB will not work! Please purchase our FSA 24.07x37 ceramic hybrid bearings separately. **
- Bottom Bracket/Frame Interface: Cannondale PF30A
- Bottom Bracket Shell Width (mm): 73mm
- Bottom Bracket Shell I.D.: 46mm
- Crank Spindle Diameter: 24.00mm
- Tool Pattern: 44mm x 16 notch$228.00 (RRP) -
Stock Code:WMBB-BBRIGHT-OUT-29
Thread together bottom bracket for frames using the BBRight™ bottom bracket standard and SRAM DUB compatible cranks with 29mm spindle diameter. Two machined aluminum cups thread together keeping the bottom bracket stable in the frame, increasing bearing life, and simplifying maintenance. This means no more creaking, smoother operation, longer bearing life, and really quick bearing replacement.
Bottom Bracket Includes:
BB Cups with bearings
2 - Silicone dust seals
2 - 0.5mm crank spindle spacers
2 - 1.0mm crank spindle spacers
1 - 2.5mm crank spindle spacer
Bottom Bracket Shell Width: 79mm
Bottom Bracket Shell I.D.: 46mm
Crank Spindle Diameter: 29mm
Tool Pattern: 48.5mm x 16 notch
Over Bearing Width: 91.5mm in 79mm wide shell*
* Over Bearing Width Dimensions include supplied silicone dust shields.$220.00 (RRP) -
Stock Code:TGBB-TGLN3922-122
Tange-Seiki LN 3922 JIS cartridge bottom bracket features ultra-smooth sealed cartridge bearings, solid boron steel spindle and steel cups.
- 68mm English-threaded (1.370" x 24 tpi)
- JIS square taper
- steel cups & sleeve
- requires Park Tool BBT-22 for installation & removal
- crank arm bolts are not included$59.00 (RRP)Add To Cart
-
Stock Code:TGBB-79220Stock Code:TGBB-79223$80.00 (RRP)$80.00 (RRP)
-
Stock Code:WTBB-BSA-29-BLK
Wolf Tooth BSA Bottom Brackets are engineered to be smooth, durable, lightweight, fast, and user-serviceable. The ground-up design features custom bearings, seals, bushings, and cups, which eliminate creaking and balance best-in-class weather sealing with optimized bearing radial compression, alignment, and preload for low drag.
The bearings in Wolf Tooth Bottom Brackets feature a custom design. The balls and race are made from a hardened chrome bearing steel. This has a higher surface hardness than stainless, which improves the durability of bearing races and reduces spinning resistance and noise. An ACOSUR ZNA coating has also been applied to the race to provide corrosion resistance that is equal to or better than stainless steel after a 500-hour saltwater test. Bearing material paired with an extensive sealing system and the elimination of metal-on-metal contact means Wolf Tooth Bottom Brackets have superior performance in all conditions.
- Compatible with 29mm spindle cranksets
- Adjustable-width sleeve fits 68mm - 73mm BSA bottom bracket shells
- Best-in-class weather sealing protects bearings from water, mud, and debris
- Custom polymer spindle bushings eliminate creaking
- Installation and removal with standard 46-12 spline tool
- Replacement parts available
- Engineered, machined, and assembled at Wolf Tooth HQ in Minnesota, USA
- Lifetime warranty on the bearings
Bottom brackets ship with the following shell and spindle spacers:
- 2x 2.5mm shell spacers
- 2x 0.5mm, 2x 1mm, 3mm, 5mm, 7.5mm 29mm spindle spacers$259.00 (RRP)Add To Cart
