Tange LN3922 73x113mm JIS
Description
Tange-Seiki LN 3922 JIS cartridge bottom bracket features ultra-smooth sealed cartridge bearings, solid boron steel spindle and steel cups.
- 73mm English-threaded (1.370" x 24 tpi)
- JIS square taper
- steel cups & sleeve
- requires Park Tool BBT-22 for installation & removal
- crank arm bolts are not included
