DH565 MONDRAKER
All Wheels Manufacturing replacement derailleur hangers are produced in Colorado shop to exacting tolerances.
- CNC machined 6061 aluminum
- Black anodized finish
- Thru Axle M12x1.75
- M5x10mm Custom Socket Head Screw
- Mondraker: M066
This hanger shares geometry with DROPOUT-566 and DROPOUT-567. DROPOUT-565 has M12x1.75 axle threads. DROPOUT-566 has M12x1.0 axle threads. DROPOUT-567 does not have threads and requires a separate axle nut. The included hanger nut has been changed from the original M15 threads to M16 for improved hanger strength. Inculded nut is not compatible with OEM hanger.
Mondraker
Crafty + - 2016-2017
Crusher Carbon + - 2019
Dune - 2017-2020
e-Crusher Carbon - 2018
Factor + - 2017
Foxy - 2017-2018
Prime - 2019
Prime + - 2019
Prime 29 - 2019
All Wheels Manufacturing replacement derailleur hangers are produced in Colorado shop to exacting tolerances.
- CNC machined 6061 aluminum
- Black anodized finish
- Thru Axle M12x1.0
- M5x10mm Custom Socket Head Screw
- Mondraker: M062R
This hanger shares geometry with DROPOUT-565 and DROPOUT-567. DROPOUT-565 has M12x1.75 axle threads. DROPOUT-566 has M12x1.0 axle threads. DROPOUT-567 does not have threads and requires a separate axle nut. The included hanger nut has been changed from the original M15 threads to M16 for improved hanger strength. Inculded nut is not compatible with OEM hanger.
Mondraker
Crafty - 2015
Dune - 2014-2016
Factor - 2014
Foxy - 2014-2016
Webshops and Bike shops
Related Products
-
Description
Attaches to frame with (2) M4x8 Flat Head Screws
Fasteners included
Replaces:
Canyon Hanger #8
Kona Hanger Type J
Marin Hanger 16
Note: This hanger has threaded holes for the fasteners.
K2
Mach - 2003
Mod - 2003
Mod - 2001-2002
Motobecane
Immortal Force -
Raleigh
Team - 2002-2004
Team Heritage - 2003
Ridley
Crosswind - 2006
Supercross - - -
Description
Attaches to frame with (1) M8 Chainring Bolt
Fastener not Included
Replaces Scott Part # 206375
Scott
29 Comp - 2011-2012
29 Elite - 2011-2012
29 Team - 2011-2012
Aspect 10, 20, 30 - 2009-2012
Aspect 29 Sport - 2012-2012
Aspect 29 Tour - 2012-2012
Aspect 29 Trail - 2012-2012
Aspect 40, 45, 50 - 2009-2012
Aspect 55, 60 - 2009-2012
Aspect 610, 620, 630 - 2013
Aspect 640, 650, 660 - 2013
Aspect 910, 920, 940, 950 - 2013
Aspect Series - 2009-2015
Atacama Sport X60 Men - 2013
Atacama Sport X70 Men - 2013
Contessa 10, 20, 30, 40, 50, 55, Tiki - 2010
Contessa 20 - 2009
Contessa 20, 30, 40, 50 - 2011
Contessa 30, 40, 50, 55 - 2009
Contessa 610, 620, 630, 640, 650, 660 - 2013
Contessa Scale 10, 20 - 2011
Contessa Scale 900 - 2013
Contessa Scale 910, 920, 930 - 2013
Contessa Scale RC - 2010
Contessa Scale Series - 2010-2011
Contessa Spark - 2011
Contessa Spark 25 - 2009
Contessa Spark 25, 35 - 2010
Contessa Spark 35 - 2009
Contessa Spark RC - 2011
Contessa Spark Series - 2010-2012
Elite & Team - 2012-2012
Metrix 20 - 2012
Scale 29 Spark - 2012
Scale 40, 50, 60, 70, 80 - 2010
Scale 640, 650, 660, 670 (TW) - 2013
Scale 70 - 2011
Scale 940, 950, 960, 970 - 2013
Scale Jr - 2009
Scale RC Jr. - 2011
Scale RC, JR, JR24 - 2010
Scale Series - 2008-2015
Spark 20, 30, 35, 40, 50, 60 - 2011
Spark 35, 40 - 2009
Spark 40, 50, 60 - 2010
Spark Series - 2009-2011
Sportster - 2008-2009
Sportster 10, 25, 30, 40, 50, 55, 60 - 2011
Sportster Series - 2009-2015
Sportster X10, X20, X30, X40, X50 - 2013
Sub 20, 30 - 2013
Sub 40 Men - 2013
Sub Series - 2008-2015
Trail & Tour - 2012
Voltage YZ 0.1, 0.2 - 2010
Voltage YZ 10 - 2013
Voltage YZ 15, 25, 35 - 2010
Voltage YZ 20 - 2013
Voltage YZ 30 - 2013
YZ30, 30, 40 - 2011 -
Description
Marin
Alpine Trail - Full Suspension - 2000-2002
Attack Trail (all) - 2000-2003
B-17 - 1998-2000
Bobcat Trail - 1998-1999
East Peak - 1999-2002
Hawk Hill/SE - 1999
Indian Fire Trial - 1993-1998
Mount Vision (all) - 1997-2002
Mount Vision Pro - 1997-2002
Nail FRS - 1996-1997
Nail Trail - 1993-2000
Palisades Trail - 1999-2000
Pine FRS - 1993-1995
Quake 5.0/7.0/8.0/9.0 - 2000-2001
Quake 5.0/9.0 - 1997
Quake Monocoque - 1996-1997
Rift Zone - 1998-2002
Rock Springs - 1999-2003
Rocky Ridge - 1993-1998
Shoreline Trail - 2001
Team DH - 2001
Team DH - 1997-1998
Team FRS - 1993-1996
Titanium FRS - 1993-1996
Wildcat Trail - 1999-2002
Wolf Ridge (all) - 2000-2003 -
Description
Attaches to frame with (1) M4x12 Socket head screw
Fastener not Included
Replaces Raleigh part #32-00-797 & 32-00-542
Raleigh
Clubman - 2016-18
Clubman Carbon - 2016-18
Merit - 2016-18
Revere 2,3 - 2016-18
Roker - 2016-18
RXC 2.0 Disc - 2016-18
RXC Disc - 2015-18
RXC Pro Disc - 2015-16
RXW - 2017-18
Willard - 2016-18 -
Description
BH
Rebel 27.5 + PWX - 2020
All Wheels Manufacturing replacement derailleur hangers are produced in our Colorado shop to exacting tolerances.
CNC machined 6061 aluminum
Black anodized finish
Attaches to frame with (1) M8 Chainring Bolt
Thru Axle Thread - M12-1.0
