CHRIS KING GRIPNUT O-RING
This factory replacement O-Ring fits Chris King® GripLock™ NoThreadSets™ only.
Webshops and Bike shops
Related Products
-
Description
EC headsets are for frames with external bearing cups, which places the bearing outside of the frame with these headsets.
Premium Headsets with Enduro stainless steel bearings have a lifetime warranty.
Wolf Tooth headsets are machined in the USA with aircraft-grade 6061 aluminum. Our headsets have three levels of superior custom sealing to protect bearings from the elements and prolong the life of the headset. They are designed to be lightweight, strong, and durable. -
Description
Chris King i7 Silver Tapered 44mm Headtube fits 1-1/8"/-1.5" tapered Steerer (convert a 44mm 1-1/8" headtube to work with a tapered steerer fork)
This Chris King® threadless headset features a bearing cap design called GripLock™. GripLock™ is a multi-piece bearing cap that utilizes a split ring that improves steerer tube interface.
A wealth of other information is available on the Chris King® website.
We guarantee to you that each Chris King® bicycle component you buy from us is absolutely brand new with full warranty, and that we are an authorized Chris King® dealer.
American made in USA
Logo Type
Bright Silver Logo
Weight: 150 grams
Warranty: 10 years
Steer tube OD: 1-1/8” to 1.5” tapered
Upper head tube bore ID (tolerances): 44.0 mm (+0, -.05)
Lower head tube bore ID (tolerances): 44.0 mm (+0, -.05)
Upper head tube ream depth: 10 mm
Lower head tube ream depth: 10 mm
Fork crown seat OD: 39.8 mm
Press fit tolerance: .1mm
Upper stack height: 8.46 mm
Lower stack height: 14.8 mm
Stem cap screw torque: 6-15 in. lbs -
Description
DropSet™ 6 is built to be precise and dependable and sets the standard for quality integrated headset function delivering precision performance that is built on the same pedigree of Chris King headsets from the past 40 years.
- 41mm 45x45 upper and lower bearing
- Engineered, manufactured and assembled in Portland, Oregon USA
- King Lifetime Warranty
- Legendary made-in-house bearings
- Patented GripLock® retention design for dependable headset adjustment (US Patent 8662517)
- Compatible with our included baseplate and 45 degree integrated crown races
